Shape cutter /Profiling Gas/ Flame Cutter Malaysia

Our Imported Profiling Gas/Flame cutter us well designed and are made of A-alloy. It is best for cutting various shapes and pieces according to the sample plate. This model is an economical version and is suitable for engineering use as well as outdoor cutting.

Specifications:

1.Weight（Body）：56.5 kg

2. Machine dimension：1190×335×800mm

3.Speed control：SCR

4.Power source：220V 50HZ

5. Cutting speed：50～750/mm/min

6. Cutting thickness：5～100mm

7. The diameter of cutting circle.：ø20～ø600mm

8. Length of cutting line.：1200mm

9. Size of cutting rectangle.：400mm×900mm, 450mm×750mm

10.Motor：55/ZYT DC110V24W   3600r/min

Items Included :

1. Main body-1set

2. Standard torch unit assemblage-1set

3. Tip (acetylene )-3pcs

4.Power wire-1pc

5. Specification sheets and certificate of qualification-1pc each

6. Gas-in connector-1set

Standard accessory

7.balance bar-2pcs

8.Heavy punch-1set

9.Sample plate of circle-1set

10.Angle-iron and connecting pipe(CG2-150A)-1pc each
